Introduction

Building a robot is one of the most exciting projects for anyone interested in STEM. In this guide, we'll build a line-following robot that can autonomously follow a black line on a white surface.

This project combines electronics, programming, and mechanical assembly - the three pillars of robotics!

Project Overview

Our robot will use infrared sensors to detect a black line and adjust its motors accordingly to follow the path.

Components Required

Component	Quantity	Purpose
Arduino Uno	1	Brain of the robot
L298N Motor Driver	1	Controls motor speed and direction
DC Motors	2	Drives the wheels
IR Sensors	2	Detects black line
Wheels	2	Movement
Caster wheel	1	Balance and support
Chassis	1	Robot body
Battery pack (9V)	1	Power supply
Jumper wires	Several	Connections

Robot Architecture

Let's understand the complete system architecture:

Assembly Steps

Step 1: Prepare the Chassis

Attach the DC motors to the motor mounts
Connect the wheels to the motor shafts
Install the caster wheel at the front

Step 2: Mount the Electronics

Secure the Arduino on the chassis
Mount the L298N motor driver
Position the IR sensors at the front

Step 3: Wiring

Connect the components according to this pin mapping:

Arduino Pin  →  Component
────────────────────────────
   5V        →  IR Sensors VCC
   GND       →  IR Sensors GND
   A0        →  Left IR Sensor OUT
   A1        →  Right IR Sensor OUT
   6         →  L298N ENA (PWM)
   7         →  L298N IN1
   8         →  L298N IN2
   9         →  L298N IN3
   10        →  L298N IN4
   11        →  L298N ENB (PWM)

The Control Logic

The robot's decision-making follows this state machine:

Arduino Code

Here's the complete code for the line-following robot:

cpp

// Pin definitions
const int leftSensor = A0;
const int rightSensor = A1;

const int ENA = 6;  // Left motor speed
const int IN1 = 7;  // Left motor direction
const int IN2 = 8;
const int IN3 = 9;  // Right motor direction
const int IN4 = 10;
const int ENB = 11; // Right motor speed

// Threshold for line detection
const int threshold = 500;

// Motor speeds
const int baseSpeed = 150;
const int turnSpeed = 100;

void setup() {
  // Set pin modes
  pinMode(leftSensor, INPUT);
  pinMode(rightSensor, INPUT);

  pinMode(ENA, OUTPUT);
  pinMode(IN1, OUTPUT);
  pinMode(IN2, OUTPUT);
  pinMode(IN3, OUTPUT);
  pinMode(IN4, OUTPUT);
  pinMode(ENB, OUTPUT);

  Serial.begin(9600);
}

void loop() {
  // Read sensor values
  int leftValue = analogRead(leftSensor);
  int rightValue = analogRead(rightSensor);

  // Print values for debugging
  Serial.print("Left: ");
  Serial.print(leftValue);
  Serial.print(" Right: ");
  Serial.println(rightValue);

  // Decision logic
  if (leftValue > threshold && rightValue > threshold) {
    // Both sensors on line - move forward
    moveForward();
  }
  else if (leftValue > threshold && rightValue < threshold) {
    // Left sensor on line - turn left
    turnLeft();
  }
  else if (leftValue < threshold && rightValue > threshold) {
    // Right sensor on line - turn right
    turnRight();
  }
  else {
    // No sensor on line - stop
    stopMotors();
  }

  delay(10);
}

void moveForward() {
  digitalWrite(IN1, HIGH);
  digitalWrite(IN2, LOW);
  digitalWrite(IN3, HIGH);
  digitalWrite(IN4, LOW);
  analogWrite(ENA, baseSpeed);
  analogWrite(ENB, baseSpeed);
}

void turnLeft() {
  digitalWrite(IN1, LOW);
  digitalWrite(IN2, HIGH);
  digitalWrite(IN3, HIGH);
  digitalWrite(IN4, LOW);
  analogWrite(ENA, turnSpeed);
  analogWrite(ENB, baseSpeed);
}

void turnRight() {
  digitalWrite(IN1, HIGH);
  digitalWrite(IN2, LOW);
  digitalWrite(IN3, LOW);
  digitalWrite(IN4, HIGH);
  analogWrite(ENA, baseSpeed);
  analogWrite(ENB, turnSpeed);
}

void stopMotors() {
  digitalWrite(IN1, LOW);
  digitalWrite(IN2, LOW);
  digitalWrite(IN3, LOW);
  digitalWrite(IN4, LOW);
  analogWrite(ENA, 0);
  analogWrite(ENB, 0);
}

Testing and Calibration

Creating a Test Track

Use black electrical tape on white paper or cardboard
Make the line about 2cm wide
Include straight sections and curves
Avoid very sharp turns initially

Calibration Tips

Adjust the threshold value based on your sensors
Fine-tune baseSpeed and turnSpeed for smooth movement
Test on different surfaces and lighting conditions

Troubleshooting

Problem	Possible Cause	Solution
Robot doesn't move	Power issue	Check battery and connections
Robot moves erratically	Sensor calibration	Adjust threshold value
Robot spins in circles	Motor wiring	Swap motor connections
Robot loses the line	Speed too high	Reduce baseSpeed

Upgrades and Improvements

Once your basic robot works, consider these upgrades:

PID Control - Smoother line following
Bluetooth Control - Remote start/stop
Obstacle Avoidance - Add ultrasonic sensors
Speed Control - Variable speed based on track complexity

Conclusion

Congratulations! You've built your first autonomous robot. This project teaches fundamental concepts of robotics including sensing, control, and actuation.

The skills you've learned here apply to more advanced robotics projects, from maze-solving robots to industrial automation systems.
